When your project demands a reliable, cost-effective board-to-board connection solution, CONSHARE’s 3.00mm pitch 180° straight pin connectors deliver the stability and performance you need. Engineered for through-hole mounting, these single-row connectors combine durable materials, precision manufacturing, and flexible customization options to solve common connection challenges – from loose contacts in high-vibration environments to performance drops in extreme temperatures. Whether you’re designing consumer electronics, industrial controls, or home appliances, these connectors are built to keep your circuits connected, no matter the conditions.

Built for Long-Lasting Reliability, Inside and Out

Flame-Resistant, Temperature-Stable LCP Housing

Unlike standard plastic housings that can warp or degrade under high heat, these connectors feature a black LCP (Liquid Crystal Polymer) housing rated UL 94V-0 for flame resistance. This material maintains its shape and structural integrity even during wave soldering, eliminating the risk of pin misalignment or housing damage during assembly. RoHS-compliant and chemically resistant, the LCP housing also stands up to harsh operating environments, including exposure to common cleaning agents used in PCB manufacturing. The compact, fork-free design keeps the footprint tight, making it ideal for space-constrained layouts without compromising on durability.

Low-Resistance, Oxidation-Resistant Copper Contacts

At the heart of every connector is a high-performance contact system designed for maximum conductivity and long-term reliability. The contacts are made from C1100 T2 copper, a material prized for its high electrical conductivity, then tin-plated to prevent oxidation and improve solderability. This combination ensures consistently low contact resistance, reducing power loss and heat buildup even at higher current loads. The matte tin-plated solder tabs provide a strong, reliable bond to the PCB, minimizing the risk of cold solder joints or connection failures over time.

Optimized Design for Hassle-Free Integration

180° Straight DIP Configuration for Through-Hole Mounting

The 180° straight DIP (Dual In-line Package) design is tailored for through-hole mounting, a proven method for creating robust, vibration-resistant connections. Unlike surface-mount connectors that can be prone to lifting in high-vibration environments, these connectors’ through-hole pins lock securely into the PCB, ensuring a stable connection even in moving or industrial equipment. The 3.00mm pitch spacing between pins is carefully calibrated to prevent electrical crosstalk and short circuits, while maintaining a compact footprint that works with standard PCB layouts.

Flexible Pin Count Options to Fit Your Project

We understand that no two designs are the same, which is why CONSHARE offers this connector series in standard pin counts of 2PIN, 4PIN, and 5PIN, with additional pin counts (up to 12PIN) available for custom orders. Whether you need a simple 2-pin connection for a power line or a multi-pin configuration for a control circuit, we can tailor the connector to your exact specifications. Our team works closely with OEM and ODM partners to adjust pin counts, tolerances, and even packaging to meet your production needs.

Engineered to Perform in Challenging Conditions

These connectors aren’t just built for standard office or home environments – they’re designed to perform reliably in a wide range of operating conditions. With a wide operating temperature range from -40°C to +105°C, they can handle everything from the cold of outdoor equipment to the heat of industrial machinery. The high insulation resistance prevents electrical leakage, while the high withstand voltage rating ensures safe operation even in high-power applications. Every connector is tested to meet strict quality standards, so you can trust that they’ll perform consistently, batch after batch.

deal Applications for CONSHARE’s 3.0mm Pitch Connectors

Thanks to their durable construction and flexible design, these connectors are a versatile choice for a wide range of industries and applications, including:

• Industrial control systems and automation equipment

• Home appliances (refrigerators, washing machines, and small kitchen appliances)

• Consumer electronics (power supplies, LED lighting, and audio devices)

• Automotive accessories (non-safety-critical components)

• Medical and test equipment (where reliable connections are a must)

• Telecommunications and networking hardware

Why Choose CONSHARE as Your Connector Partner?

At CONSHARE, we’re more than just a connector supplier – we’re your partner in building better products. Here’s why our customers trust us for their connection needs:

• Rigorous Quality Control: Every connector in this series undergoes comprehensive testing for electrical performance, mechanical durability, and environmental resistance, ensuring consistent quality across every batch.

• Customization Support: We offer flexible customization options, from pin counts to packaging, to help you solve unique design challenges. Our engineering team is available to provide technical support and design guidance throughout your project.

• Cost-Effective Solutions: Our optimized manufacturing processes allow us to deliver high-quality connectors at competitive prices, helping you reduce production costs without sacrificing performance.

• RoHS-Compliant Products: All our connectors meet international RoHS standards, making them suitable for export to markets around the world.

Quick Reference Specifications

Ready to find the perfect connector for your next project? The CONSHARE team is here to help. Contact us today to discuss customization options, bulk orders, or technical support, and let’s build a connection that works for you.
