As a vertical-mount connector (180° orientation) in the SlimSAS family, the A86W00274ASF03 (REV.3) complies with the SFF 8654 standard. It is a high-speed interconnect solution specifically designed for storage devices where installation height is not strictly constrained.
Core Technical Features:
Adopts a 0.60 mm pitch interconnect system, delivering superior signal integrity compared to standard Mini SAS solutions and meeting the requirements of the SAS-4 (T10) standard.
Supports both internal and external I/O applications, compatible with multiple assembly options and adaptable to unshielded connector designs.
Addresses key pain points of next-generation storage devices: overcomes form factor limitations of bulk cables and meets the high-speed transmission needs of multi-lane storage equipment.
The REV.3 version has undergone multiple rounds of performance optimization, featuring enhanced signal stability and mechanical reliability. It is well-suited for long-term, high-load operating scenarios.
◆◆ Product Advantage
High-Density Space Optimization: Features a low-profile package design with a 0.60mm pitch, significantly saving PCB space. The 8X configuration occupies the same footprint as 4X Mini SAS HD, achieving "small size with high bandwidth.
High-Speed Performance Compliance: Complies with the SAS 4.0 standard, supporting a transmission rate of 24 Gb/s and compatible with PCIe Gen 4, meeting the high-speed data requirements of next-generation storage devices.
Dual-Scenario Compatibility: Supports both internal and external I/O applications. The receptacle is compatible with pluggable modules, reducing the number of device interface types and lowering design complexity.
Industry Standard Compliance: Strictly adheres to the T10/Serial Attached SCSI (SAS-4) standard, offering strong versatility and seamless compatibility with mainstream SlimSAS devices.
Superior Signal Integrity: Boasts stronger anti-interference capability compared to standard Mini SAS solutions, enabling stable transmission of high-speed signals and reducing the risk of data loss.
Small Form Factor (SFF): Designed with a small form factor, it is compatible with various compact electronic devices, balancing "performance" and "size" requirements
Vertical Mount Adaptability: Features a 180° vertical orientation design, suitable for scenarios without strict installation height restrictions (such as servers and large storage arrays). It allows more flexible wiring and easier insertion/extraction during maintenance.
Proven Version Reliability: The REV.3 version has undergone multiple iterations, with more durable mechanical structures (e.g., latches and contacts). Its insertion/extraction life is 30% longer than the base version, reducing the risk of failures during long-term use.
