As a right-angle SMT-mount connector (8X lane) in the SlimSAS family, the A86W10274ASF30-1 is a compact, high-speed interconnect solution specifically designed for high-density PCB layouts and height-constrained scenarios.
Core Technical Features:
Supports both internal and external I/O applications, utilizing SMT (Surface Mount Technology) that is compatible with automated mass production and saves space on the back of the PCB.
Addresses key pain points of next-generation storage devices: overcomes form factor limitations of bulk cables, with a fixed 8X lane configuration that precisely matches mid-to-high bandwidth transmission needs.
Optimized for compact devices: The right-angle (90°) mounting design reduces PCB height space requirements, making it suitable for constrained scenarios such as blade servers and small industrial computers.
◆◆ Product Advantage
High-Density Space Optimization: Features a low-profile package design with a 0.60mm pitch, significantly saving PCB space. The 8X configuration occupies the same footprint as 4X Mini SAS HD, achieving "small size with high bandwidth.
High-Speed Performance Compliance: Complies with the SAS 4.0 standard, supporting a transmission rate of 24 Gb/s and compatible with PCIe Gen 4, meeting the high-speed data requirements of next-generation storage devices.
Dual-Scenario Compatibility: Supports both internal and external I/O applications. The receptacle is compatible with pluggable modules, reducing the number of device interface types and lowering design complexity.
Industry Standard Compliance: Strictly adheres to the T10/Serial Attached SCSI (SAS-4) standard, offering strong versatility and seamless compatibility with mainstream SlimSAS devices.
Superior Signal Integrity: Boasts stronger anti-interference capability compared to standard Mini SAS solutions, enabling stable transmission of high-speed signals and reducing the risk of data loss.
Right-Angle Mount Space Saving: Adopts a 90° right-angle design, with the connector body perpendicular to the PCB. It reduces installation height requirements by 60%, perfectly fitting height-constrained scenarios such as laptops, small industrial computers, and blade servers.
Resonance Damping Optimization: Incorporates a built-in resonance damping structure, enhancing customizable signal integrity. It supports NVLink 25G transmission and maintains signal stability even in high-frequency scenarios (AI servers).
Blade Server Compatibility: Optimized for the dense layout of blade servers, its size and thermal design match blade architectures. It enables mass deployment without compromising the overall thermal efficiency of the equipment.
