Board to Board Connector
Industrial, IT Datacom
Tailored perfectly to match MXM 6.0 interface specifications, this premium high-speed connector from CONSHARE can achieve peak data transmission speed reaching 16GT/s. Equipped with total 314 finely crafted pins, it maintains steady and uninterrupted signal connection, perfectly fitting embedded graphic modules and industrial GPU computation scenarios.
Adopting 5 micro-inch gold-plated copper alloy contact points together with UL94V-0 fire-resistant LCP shell material, this connector boasts outstanding anti-rust capability and reliable safety features. It can work steadily within the temperature range from -40°C to 85°C and fully complies with RoHS environmental norms, suiting long-duration industrial field deployment.
This right-angle surface mount type connector features 6.0mm board mounting height and 0.5mm pin pitch, which is fully compatible with standard reflow soldering processes. The streamlined high-density layout saves much installation space, making it the ideal choice for compact and tough electronic hardware solutions.
CONSHARE’s MXM connector supports blazing-fast 16GT/s data transfer, meeting the strict bandwidth demands of embedded graphics and high-performance computing systems. The 314-pin layout ensures robust signal integrity, and we offer custom pin configurations to match your specific system architecture.
Engineered with premium 5u gold-plated contacts, this CONSHARE 314P MXM connector delivers exceptional corrosion resistance and wear performance, maintaining stable electrical connections over extended use. It fully complies with RoHS standards, and we can adjust plating thicknesses to meet your environmental requirements.
Featuring a compact 6.0H height profile, this CONSHARE MXM connector is ideal for slim, space-saving embedded devices without compromising mechanical stability. Its durable housing withstands vibration and shock, and we provide custom height modifications to fit your unique enclosure design needs.
As a professional connector manufacturer, CONSHARE offers full customization for this MXM 6.0 connector, including pin count, plating specifications, and mechanical dimensions. Whether you need a modified layout or specialized material options, we adapt our solutions to align perfectly with your application’s technical demands.
Every CONSHARE MXM connector undergoes rigorous testing to ensure consistent performance and reliability in industrial and embedded environments. From signal integrity checks to environmental compliance, we uphold strict quality standards, and we can provide custom testing reports to support your product certification needs.
Parameter | Specification |
|---|---|
Brand | CONSHARE |
Product Type | MXM Board-to-Board Connector |
Gender | Receptacle (Female) |
Pin Count | 314 Pins |
Pitch | 0.5 mm |
Board Height | 6.0 mm |
Configuration | Right Angle (90°) |
Solder Type | SMD |
Contact Plating | Gold (Au) 5µ" |
Max Data Rate | 16 GT/s |
Compliance | RoHS Compliant |
Operating Temperature | -40°C ~ 85°C |
Packaging | Tape & Reel |
Customization | Available |
It works perfectly for embedded graphic hardware, delivering steady high-speed signal transmission to ensure smooth image rendering and stable graphic output under long-duration running states.
Ideal for high-performance computing devices, sufficient bandwidth supports rapid data processing, greatly boosting overall operating efficiency of computing terminal equipment.
Suits slim-style embedded industrial devices well, its low-profile structure fits narrow installation space while keeping strong shock and vibration resistance for stable field operation.
Applicable to industrial control system modules, reliable electric connection and eco-friendly material design adapt to various harsh working environments to secure continuous system operation.
Matches customized electronic hardware development projects, flexible pin layout and adjustable structural specs can meet diversified assembly and technical matching demands of different project designs.
A: This CONSHARE MXM connector supports PCIe Gen4 signaling at up to 16GT/s, ensuring stable, low-loss high-speed transmission for industrial graphics modules and embedded systems.
A: Yes. It is fully RoHS-compliant, built with UL 94V-0 rated LCP housing, and operates reliably across -40°C to 85°C, ideal for industrial and embedded applications.
A: Absolutely. CONSHARE offers flexible customization, including plating thickness, board height, and polarization adjustments, with engineering support from prototypes to volume orders.
A: This right-angle SMT connector is optimized for reflow soldering and comes in tape-and-reel packaging, supporting high-volume automated assembly for efficient production.
